Distrahierbarer Wirbelkörperersatz für die thorakale und lumbale Wirbelsäule Expandable Vertebral Body Replacement for Thoracic and Lumbar Spine ALSO AVAILABLE IN STERILE PACKAGING THORACIC / LUMBAR SPINE
Medicon eG Gänsäcker 15 · D-78532 Tuttlingen · Germany · Tel.: +49 (0) 74 62 / 20 09-0 Fax: +49 (0) 74 62 / 20 09-50 · E-Mail: sales@medicon.de · Internet: www.medicon.de Konnektorteil und Zugangsmöglichkeiten n Für spezielle Winkelverbindungen mit dem Einbringinstrument n Für lateralen Zugang n Für dorsolateralen Zugang/TLIF-Technik Implant Insertion: Lateral and Posterolateral n For angular connection with the insertion instrument n Lateral approach n Posterolateral approach/TLIF technique Modular.Flexibel.Effizient. n "Verlängerung" und "gewinkelte Endplatte" sind beidseitig ein- setzbar n Gezahnte Endplatten bieten einen optimalen Dislokations- schutz n Die adaptierbar gewinkelte Endplatte ermöglicht eine opti- male Anpassung an die anato- mischen Gegebenheiten (Lor- dosewinkel bis 30°) Modular. Flexible. Efficient. n Extension and angled end plate can be used on both sides n Toothed end plates provide optimum dislocation protection n The adaptable angulated end plate allows for an optimal adaptation to the anatomical conditions (lordosis angle up to 30°) Stufenloses Distrahieren n Das Implantat ermöglicht eine einstellbare Expansion und Prä- zisionsanpassung von bis zu 66% der ursprünglchen Implantat- größe. n Die 2 Säulen-Architektur führt zu einer erhöhten Stabilität und er- möglicht eine bessere Gewichts- verteilung. Variable Expansion n The implant allows an adjustable expansion and precision height adjustment of up to 66% of the original implant size. n The 2-pillar architecture leads to increased stability and allows for better weight distribution. Implantatgrößen Implant Sizes a b c 15.0 - 24.0 mm 16.0 mm 24.0 mm 15.0 - 24.0 mm 18.0 mm 28.0 mm 18.0 - 28.0 mm 16.0 mm 24.0 mm 18.0 - 28.0 mm 18.0 mm 28.0 mm 24.0 - 38.0 mm 18.0 mm 28.0 mm 18.0 - 28.0 mm 22.0 mm 35.0 mm 18.0 - 28.0 mm 22.0 mm 38.0 mm 22.0 - 34.0 mm 22.0 mm 35.0 mm 22.0 - 34.0 mm 22.0 mm 38.0 mm 30.0 - 50.0 mm 22.0 mm 35.0 mm 30.0 - 50.0 mm 22.0 mm 38.0 mm b a c Dorsolateraler Zugang Posterolateral approach Lateraler Zugang Lateral approach Distraktionsanschlag Expansion limiter 2° / 5° 10° / 15° 2° / 5° 10° / 15° Distrahierbarer Wirbelkörperersatz Expandable Vertebral Body Replacement Produktvideo Product video Not all products illustrated in this documentation are available for sale in all countries. Not for all declared products in this documentation Medicon is the legal manufacturer. Please contact your local distributor for more information concerning availability and regulatory information (e.g. classification) of the mentioned products. © Copyright 12/2024, MEDICON eG, Tuttlingen, Germany
